Chinese Journal of Management Science ›› 2025, Vol. 33 ›› Issue (7): 200-209.doi: 10.16381/j.cnki.issn1003-207x.2022.1425
Received:
2022-06-30
Revised:
2023-05-14
Online:
2025-07-25
Published:
2025-08-06
Contact:
Wuliang Peng
E-mail:wuliang.p@ytu.edu.cn
CLC Number:
Wuliang Peng, Xuejun Lin. A Dynamic Reactive Scheduling Method for the Resource Constrained Project Scheduling Problem[J]. Chinese Journal of Management Science, 2025, 33(7): 200-209.
"
序号 | 完工集 | 进行集 | 候选集 | 选择集 | 成本值 |
---|---|---|---|---|---|
1 | 0 | 1,2,3 | 1,3 | 40.17 | |
2 | 0 | 1,2,3 | 2 | 12.59 | |
3 | 0,1 | 3 | 37.42 | ||
4 | 0,1,2 | 4 | 3 | 3 | 10.18 |
5 | 0,1,2 | 3 | 4 | 4 | 13.67 |
6 | 0,1,2,3 | 4,5 | 4,5 | 26.29 | |
7 | 0,1,2,3 | 4 | 5 | 5 | 10.33 |
8 | 0,1,2,3,4 | 5 | 5 | 15.50 | |
9 | 0,1,2,3,4 | 5 | 10.75 | ||
10 | 0,1,2,3,4,5 | 6 | 6 | 32.17 | |
11 | 0,1,2,3,4,5,6 | 7 | 7 | 32.17 | |
12 | 0,1,2,3,5 | 4 | 4 | 43.98 | |
13 | 0,1,2,3,5 | 4 | 22.24 | ||
14 | 0,1,2,4 | 3 | 13.00 | ||
15 | 0,1,3 | 2,5 | 5 | 45.56 | |
16 | 0,1,3 | 2,5 | 2 | 28.06 | |
17 | 0,1,3 | 5 | 42.93 | ||
18 | 0,1,3,5 | 2 | 2 | 43.98 | |
19 | 0,2 | 1,3,4 | 1,4 | 10.18 | |
20 | 0,2 | 1,3,4 | 3,4 | 12.71 | |
21 | 0,2 | 1,3,4 | 1,3 | 14.91 | |
22 | 0,2,3 | 4 | 1,5 | 1 | 12.71 |
23 | 0,2,3 | 1 | 4,5 | 4 | 12.00 |
24 | 0,2,3,4 | 1 | 5 | 5 | 11.00 |
25 | 0,3 | 1 | 5 | 5 | 41.68 |
"
任务数 | 分布类型 | 生成查找表时间(秒) | 状态数 | 调度时间(秒) | 偏差值 | 近似次数 |
---|---|---|---|---|---|---|
30 | U1 | 34.70 | 4373.11 | 0.48 | 86.14 | 0.13 |
U2 | 59.57 | 7848.40 | 0.79 | 183.85 | 0.62 | |
Exp | 68.35 | 9179.00 | 0.86 | 292.97 | 0.71 | |
B1 | 32.57 | 4263.04 | 0.46 | 87.49 | 0.16 | |
B2 | 32.97 | 4326.97 | 0.47 | 93.78 | 0.19 | |
60 | U1 | 479.84 | 31561.96 | 7.41 | 276.72 | 3.38 |
U2 | 635.42 | 40676.42 | 9.08 | 437.24 | 4.92 | |
Exp | 645.71 | 40862.00 | 9.40 | 626.7 | 5.26 | |
B1 | 454.43 | 30922.18 | 7.12 | 254.74 | 2.86 | |
B2 | 507.42 | 31280.84 | 7.39 | 263.12 | 3.27 | |
120 | U1 | 4903.26 | 136978.46 | 113.30 | 776.14 | 19.02 |
U2 | 5433.65 | 147150.80 | 117.83 | 1207.16 | 19.40 | |
Exp | 5783.09 | 148741.72 | 124.15 | 1585.60 | 19.86 | |
B1 | 4356.48 | 136148.24 | 117.37 | 777.52 | 19.20 | |
B2 | 4853.13 | 136717.36 | 118.23 | 806.00 | 19.28 |
[1] | Kolisch R, Hartmann S. Experimental investigation of heuristics for resource-constrained project scheduling: An update[J]. European Journal of Operational Research, 2006, 174(1): 23-37. |
[2] | 马志强,徐小峰,何正文,等. 复杂不确定环境下活动可拆分的项目资源鲁棒性调度优化[J]. 中国管理科学, 2022, 30(3):117-130. |
Ma Z Q, Xu X F, He Z W, et al. Robust scheduling optimization of project resources with activity splitting under complex and uncertain environments[J]. Chinese Journal of Management Science, 2022,30(3):117-130. | |
[3] | Herroelen W, Leus R. Project scheduling under uncertainty: Survey and research potentials[J].European Journal of Operational Research, 2005,165(2): 289-306. |
[4] | 谢芳, 李洪波, 柏庆国. 随机多模式资源受限项目调度 [J]. 中国管理科学, 2022,23(10): 155-164. |
Xie F, Li H B, Bai Q G. Stochastic multi-mode resource-constrained project scheduling[J]. Chinese Journal of Management Science,2022,23(10): 155-164. | |
[5] | Chakrabortty R K, Abbasi A, Ryan M J. Multi-mode resource-constrained project scheduling using modified variable neighborhood search heuristic [J]. International Transactions in Operational Research, 2020, 27(1): 138-167. |
[6] | Larsen R, Pranzo M. A framework for dynamic rescheduling problems [J]. International Journal of Production Research, 2019, 57(1): 16-33. |
[7] | Chakrabortty R K, Sarker R A, Essam D L. Multi-mode resource constrained project scheduling under resource disruptions [J]. Computers & Chemical Engineering, 2016, 88: 13-29. |
[8] | Chakrabortty R K, Rahman H F, Haque K M A, et al. An event-based reactive scheduling approach for the resource constrained project scheduling problem with unreliable resources[J]. Computers & Industrial Engineering, 2021, 151: 106981. |
[9] | Van de Vonder S, Ballestín F, Demeulemeester E, et al. Heuristic procedures for reactive project scheduling[J]. Computers & Industrial Engineering, 2007, 52(1):11-28. |
[10] | 崔晓, 何正文, 王能民. 资源约束应急救援多模式项目反应性调度优化[J]. 工业工程与管理, 2018, 23(5): 24-32+43. |
Cui X, He Z W, Wang N M. Reactive scheduling optimization for multi-mode project of emergency rescue under resource constrains[J]. Industrial Engineering and Management, 2018, 23(5): 24-32+43. | |
[11] | Chakrabortty R K, Sarker R A, Essam D L. Multi-mode resource constrained project scheduling under resource disruptions[J]. Computers & Chemical Engineering, 2016, 88: 13-29. |
[12] | Lamas P, Demeulemeester E. A purely proactive scheduling procedure for the resource-constrained project scheduling problem with stochastic activity durations [J]. Journal of Scheduling, 2016, 19(4): 409-428. |
[13] | Deblaere F, Demeulemeester E, Herroelen W. Reactive scheduling in the multi-mode RCPSP[J]. Computers & Operations Research, 2011, 38(1): 63-74. |
[14] | Panda D, Bayu F, Ramteke M. Discrete time reactive scheduling of gasoline blending and product delivery in presence of demand and component uncertainties using graphical genetic algorithm[J]. Computers & Chemical Engineering, 2020, 143: 107100. |
[15] | Ashtiani B, Leus R, Aryanezhad M B. New competitive results for the stochastic resource-constrained project scheduling problem: Exploring the benefits of pre-processing[J]. Journal of Scheduling, 2011, 14(2): 157-171. |
[16] | Chen Z, Demeulemeester E, Bai S J, et al. Efficient priority rules for the stochastic resource-constrained project scheduling problem [J]. European Journal of Operational Research, 2018, 270(3): 957-967. |
[17] | Xie F, Li H T, Xu Z. An approximate dynamic programming approach to project scheduling with uncertain resource availabilities[J]. Applied Mathematical Modelling, 2021, 97: 226-243. |
[18] | Choi J, Realff M J, Lee J H. Dynamic programming in a heuristically confined state space: A stochastic resource-constrained project scheduling application [J]. Computers & Chemical Engineering, 2004, 28(6-7): 1039-1058. |
[19] | Creemers S. Minimizing the expected make span of a project with stochastic activity durations under resource constraints [J]. Journal of Scheduling, 2015, 18(3): 263-273. |
[20] | Creemers S. The preemptive stochastic resource-constrained project scheduling problem[J]. European Journal of Operational Research, 2019,277(1): 238-247. |
[21] | Satic U, Jacko P, Kirkbride C. Performance evaluation of scheduling policies for the dynamic and stochastic resource-constrained multi-project scheduling problem[J]. International Journal of Production Research, 2022, 60(4): 1411-1423. |
[22] | Choi J, Realff M J, Lee J H. A Q-Learning-based method applied to stochastic resource constrained project scheduling with new project arrivals[J]. International Journal of Robust and Nonlinear Control, 2007, 17(13): 1214-1231. |
[23] | 谢芳,徐哲,于静.资源可用量不确定和活动多模式情形下的随机项目调度问题[J]. 管理工程学报, 2022, 36(3): 170-178. |
Xie F, Xu Z, Yu J. Stochastic scheduling of projects with uncertain resource availabilities and multiple modes[J]. Journal of Industrial Engineering and Engineering Management, 2022, 36(3): 170-178. | |
[24] | Li H T, Womer N K. Solving stochastic resource-constrained project scheduling problems by closed-loop approximate dynamic programming[J]. European Journal of Operational Research, 2015, 246(1): 20-33. |
