应对潮汐客流的城市轨道交通列车跳站运行优化

doi:10.16381/j.cnki.issn1003-207x.2022.1317

中国管理科学 ›› 2025, Vol. 33 ›› Issue (3): 256-263.doi: 10.16381/j.cnki.issn1003-207x.2022.1317cstr: 32146.14/j.cnki.issn1003-207x.2022.1317

应对潮汐客流的城市轨道交通列车跳站运行优化

梁辉¹, 景云¹^,³(), 田志强²^,⁴, 宋琦², 朱卯午²

^1.北京交通大学交通运输学院，北京 100044
^2.兰州交通大学交通运输学院，甘肃兰州 730070
^3.北京交通大学智慧高铁系统前沿科学中心，北京 100044
^4.兰州交通大学高原铁路运输智慧管控铁路行业重点实验室，甘肃兰州 730070

收稿日期:2022-06-16 修回日期:2022-08-21 出版日期:2025-03-25 发布日期:2025-04-07
通讯作者: 景云 E-mail:yjing@bjtu.edu.cn
基金资助:
国家自然科学基金项目(52372300);中国铁路北京局集团有限公司科技研究开发计划课题(2023BK02);兰州交通大学交通运输学院青年科学基金项目(YQN202204)

Optimization of Train Skip-stop Operation on Tidal Overcrowded Metro Lines

Hui Liang¹, Yun Jing¹^,³(), Zhiqiang Tian²^,⁴, Qi Song², Maowu Zhu²

^1.School of Traffic and Transportation，Beijing Jiaotong University，Beijing 100044，China
^2.School of Traffic and Transportation，Lanzhou Jiaotong University，Lanzhou 730070，China
^3.Frontiers Science Center for Smart High-speed Railway Systemss，Beijing Jiaotong University，Beijing 100044，China
^4.Key Laboratory of Railway Industry on Plateau Railway Transportation Intelligent Management and Control，Lanzhou Jiaotong University，Lanzhou 730070，China

Received:2022-06-16 Revised:2022-08-21 Online:2025-03-25 Published:2025-04-07
Contact: Yun Jing E-mail:yjing@bjtu.edu.cn

摘要/Abstract

摘要：

由于城市轨道交通潮汐客流在时间和空间的分布不均，造成大客流方向乘客滞留严重和小客流方向列车能力冗余等问题。本文从交通需求的角度出发，分别以滞站人数最小和乘客在车时间最短为优化目标，构建考虑跳站策略的城市轨道交通时刻表优化模型，并采用模拟退火算法进行求解。为验证模型和算法的有效性，以某城市轨道交通线路实际运营数据为背景，结果表明：通过运用调整列车发车间隔和列车跳站的协同优化策略，滞站乘客总人数减少7.1%，总的乘客在车时间减少2.2%。最后，针对跳站次数进行灵敏度分析，可为运营方提供了多种选择策略。

关键词: 城市轨道交通, 潮汐客流, 双目标优化, 列车时刻表, 跳站模式

Abstract:

Due to the uneven distribution of tidal passenger flow in time and space of urban rail transit， the passengers in the direction of large passenger flow are seriously delayed in the station and the train capacity in the direction of small passenger flow is redundant. From the perspective of traffic demand， the minimum number of delayed passengers in the station and the minimum time of passengers in the train is taken as the optimization objectives respectively， and the urban rail transit timetable optimization model considering the skip-stop strategy is constructed and the simulated annealing algorithm is used to solve it. In order to verify the validity of the model and the algorithm， based on the actual operation data of an urban rail transit line， the results show that by using the cooperative optimization strategy of adjusting the train headway and train skip-stop pattern， the total number of delayed passengers in the station is reduced by 7.1%， and the total time of passengers in the train is reduced by 2.2%. Finally， the sensitivity analysis of the number of jumping stations can provide a variety of selection strategies for operators.

Key words: urban rail traffic, tidal passenger flow, bi-objective optimization, train timetable, skip-stop pattern

中图分类号:

U292.4

梁辉, 景云, 田志强, 宋琦, 朱卯午. 应对潮汐客流的城市轨道交通列车跳站运行优化[J]. 中国管理科学, 2025, 33(3): 256-263.

Hui Liang, Yun Jing, Zhiqiang Tian, Qi Song, Maowu Zhu. Optimization of Train Skip-stop Operation on Tidal Overcrowded Metro Lines[J]. Chinese Journal of Management Science, 2025, 33(3): 256-263.

图/表 11

图1

图2

图3

表1

表2

表3

表4

图4

表5

表6

表7

参考文献 13

1	许得杰，毛保华，陈绍宽，等.考虑开行比例的大小交路列车开行方案优化［J］.交通运输工程学报， 2021， 21（2）：173-186.
	Xu D J， Mao B H， Chen S K， et al. Optimization of operation scheme for full-length and short-turn routings considering operation proportion［J］. Journal of Traffic and Transportation Engineering， 2021， 21（2）： 173-186.
2	汤莲花，徐行方.基于双层规划的市郊轨道交通多交路快慢车开行方案优化研究［J］.交通运输系统工程与信息，2018，18（3）：152-159.
	Tang L H， Xu X F. Optimizing train plan with multi-routing and express-local modes for suburban rail transit based on bi-level programming［J］. Journal of Transportation Systems Engineering and Information Technology， 2018，18（3）：152-159.
3	王媛媛，倪少权.城市轨道交通大小交路模式列车开行方案的优化［J］.铁道学报，2013，35（7）：1-8.
	Wang Y Y， Ni S Q. Optimization of train schedules of full-length & short-turn operation modes in urban rail transit［J］. Journal of the China Railway Society， 2013，35（7）：1-8.
4	徐轲非. 考虑多编组的城市轨道交通Y型线路列车开行方案研究［D］.北京：北京交通大学硕士论文，2021.
	Xu K F. Study on train operation scheme of y-type line in urban rail transit with multiple groups considered［D］. Beijing：Beijing Jiaotong University，2021.
5	石修路，蔡肇萍.重庆市轨道交通27号线快慢车模式研究［J］.交通运输工程与信息学报，2021，19（2）：74-83.
	Shi X L， Cai Z P. Express/slow urban rail transit of line 27 in chongqing［J］. Journal of Traffic and Transportation Engineering， 2021，19（2）：74-83.
6	张红健. 轨道交通市域线多交路快慢车开行方案研究［D］.北京：北京交通大学硕士论文，2020.
	Zhang H J. Study on train planning optimization of express-local combined with multi-routing［D］. Beijing：Beijing Jiaotong University， 2020.
7	Shang P， Li R， Liu Z， et al. Equity-oriented skip-stopping schedule optimization in an oversaturated urban rail transit network［J］. Transportation Research Part C： Emerging Technologies， 2018， 89： 321-343.
8	Jiang F， Cacchiani V， Toth P. Train timetabling by skip-stop planning in highly congested lines［J］. Transportation Research Part B： Methodological， 2017， 104： 149-174.
9	吴文祥，赵浩淋，周慧娟，等.高峰期城市轨道交通列车跳站运行优化［J］.交通运输工程与信息学报， 2022，20（2）：42-59.
	Wu W X， Zhao H L， Zhou H J， et al. Optimization of train skip-stop operation on urban rail transit transit lines during peak hours［J］. Journal of Transportation Systems Engineering and Information Technology， 2022，20（2）：42-59.
10	杨陶源，赵鹏，姚向明，等.轨道交通延误条件下列车跳站与客流控制协同优化模型［J］.交通运输系统工程与信息，2021，21（2）：105-110+132.
	Yang T Y， Zhao P， Yao X M， et al. Coordinated optimization model of rail transit delayed train stop-skip pattern and passenger flow control［J］. Journal of Transportation Systems Engineering and Information Technology， 2021，21（2）：105-110+132.
11	Niu H， Zhou X， Gao R. Train scheduling for minimizing passenger waiting time with time-dependent demand and skip-stop patterns： Nonlinear integer programming models with linear constraints［J］. Transportation Research Part B： Methodological， 2015， 76： 117-135.
12	冉昕晨，陈绍宽，柏赟，等.应对潮汐客流的城市轨道交通列车节能和乘客节时运行图优化模型［J］.中国铁道科学，2022，43（1）：171-181.
	Ran X C， Chen S K， Bai Y， et al. Train energy-efficient and passenger time-saving timetable optimization model for urban rail transit line with tidal passenger flow［J］. China Railway Science， 2022，43（1）：171-181.
13	蒋琦玮，苏建凯，陈维亚.考虑跨站停车的地铁客流协同控制模型［J］.铁道科学与工程学报， 2021，18（11）：2857-2864.
	Jiang Q W， Su J K， Chen W Y. Collaborative control model of metro passenger flow considering skip-stop strategy［J］. Journal of Railway Science and Engineering， 2021，18（11）：2857-2864.

车站	1	2	3	4	5	6	7	8	9	10	11	12
等级	高	高	高	高	中	中	中	中	低	低	低
G	60	60	60	60	50	50	50	40	40	40	40	0
D	50	50	50	50	40	40	40	30	30	30	30	0

列车车站	2	4	6	8	10	12	14	16	18	20	22	24	26	28	30	32	34	36	38	40	42	44	46	48
12	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1
11	1/1	1/1	1/1	1/0	1/1	1/1	1/0	1/0	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/0	1/0	1/1	1/1	1/0	1/1	1/0	1/1	1/1
10	1/1	1/1	1/1	1/1	1/1	1/1	1/0	1/0	1/1	1/0	1/1	1/1	1/0	1/0	1/1	1/1	1/0	1/1	1/1	1/0	1/1	1/0	1/1	1/1
9	1/0	1/1	1/1	1/0	1/0	1/1	1/0	1/0	1/1	1/0	1/0	1/1	1/1	1/1	1/1	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/1	1/1
8	1/1	1/1	1/1	1/0	1/1	1/1	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/0	1/1	1/0	1/0	1/1	1/0	1/1	1/1	1/0	1/1	1/0
7	1/0	1/0	1/1	1/1	1/0	1/1	1/1	1/1	1/1	1/0	1/1	1/1	1/1	1/0	1/1	1/1	1/0	1/1	1/0	1/0	1/1	1/0	1/1	1/0
6	1/0	1/0	1/1	1/0	1/1	1/1	1/0	1/1	1/1	1/0	1/0	1/1	1/1	1/0	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/0	1/1	1/0
5	1/0	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/0	1/0	1/1	1/1	1/0	1/1	1/0	1/1	1/1	1/0	1/0	1/1	1/0	1/1	1/1
4	1/0	1/0	1/1	1/1	1/0	1/1	1/0	1/1	1/1	1/1	1/0	1/1	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/0	1/1	1/1
3	1/0	1/1	1/1	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/1	1/0	1/1	1/1	1/1	1/0
2	1/0	1/0	1/1	1/0	1/1	1/1	1/1	1/1	1/1	1/1	1/0	1/1	1/0	1/1	1/1	1/1	1/0	1/1	1/1	1/0	1/1	1/1	1/1	1/0
1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1	1/1

跳站次数取值范围	实际跳站次数	滞留乘客总数/人	乘客平均在车时间/分钟	发车间隔/分钟
[50,60)	57	23589	13.2	[5,6,7,2,2,8,4,2,3,4,6,4,4,7,5,3,6,5,6,7,6,3,7,8]
[60,70)	66	24403	13.4	[5,8,6,4,3,6,5,4,3,7,3,6,2,3,6,2,6,4,4,5,5,8,7,8]
[70,80)	76	28797	14.3	[5,6,8,4,3,6,3,4,4,6,3,4,6,2,4,6,3,6,7,2,8,5,7,8]
[80,90)	83	31261	14.6	[5,7,3,2,6,8,2,4,4,3,4,5,6,3,5,4,4,5,4,4,8,8,8,8]
[90,100)	90	32607	15.0	[5,6,4,4,7,5,5,2,5,3,4,8,2,3,2,5,5,6,3,5,8,7,8,8]
